#106312 Moll Regal Units
2007 Versa Fold STP Folder Gluer w/ Tipper Plate (Dial-a-stack w/ batch counter w/ Dynamini 2 Line Glue System)
2012 26" Bottom Friction Feeder - Final Fold Unit (Dynamini 2 Line Glue System - with 2 tape heads)
Moll Regal 2012 26" Bottom Friction Feeder – Final Fold Unit Specifications
The
Moll Regal is a long-in-feed, belt-driven folder/gluer system designed for high-speed, multi-panel folding and gluing. The
Final Fold section completes the folding sequence, and the
26" bottom friction feeder is a common configuration for this model.
Core Specifications
- Format: 30" wide (762 mm) maximum sheet size
- Minimum sheet size: ~5.5" x 5.5" (139 x 139 mm)
- Stock range: 70 lb cover to 28 pt board (approx. 140–500 g/m²)
- Maximum linear speed: 425 ft/min (130 m/min)
- Feeding system: Bottom friction feeder (26" width) for consistent sheet separation and feeding
- Folding plates: Adjustable buckle fold plates with removable ribs; optional tipper fold plate with dual anti-marking rollers for heavier stocks
- Glue system: Hot melt and/or cold glue compatible
- Power connection: 220V, 3-phase, 30A, 60 Hz; or 400V, 3-phase, 30A, 50 Hz
- Compressed air: ~90 PSI (0.7 MPa)
Moll Regal 2007 Versa-Fold STP Folder Gluer — Specifications
The
Moll Regal 2007 Versa-Fold is a belt-driven, all-in-one folder/gluer designed for high-speed folding, forming, and gluing of printed materials. It combines the robust Regal system with the
Versa-Fold module for flexible folding layouts and the
STP (Tipper Plate) for heavy-stock folding.
Core Specifications
- Format: 30" wide (762 mm)
- Minimum product size: 5.5" × 5.5" (139 × 139 mm)
- Maximum product size: 30" × 30" (762 × 762 mm)
- Stock range: 70 lb cover to 28 pt board (140–500 g/m²)
- Max linear speed: 425 ft/min (130 m/min)
- Power: 220V, 3-phase, 30A, 60 Hz; 400V, 3-phase, 30A, 50 Hz
- Compressed air: 90 PSI (0.7 MPa)
- Drive: All belt-driven transport
- Fold plates:
- Buckle fold plate (stainless steel back plate, removable ribs)
- Tipper fold plate with dual anti-marking rollers for heavier stocks
