#106426 2019 Oce i300 Color Ink Jet Production Printer

• Print Technology: Inkjet, drop-on-demand, piezoelectric
• Ink: Proprietary, water-based pigment ink
• Drop Size: Variable, Multi-level
• Print Speed (images/min)
  • VarioPrint i300: 300 A4 images / 153 A3 images duplex
  • VarioPrint i300: 175 A4 images / 94 A3 images simplex

• Specialty Speed (images/min)
  • VarioPrint i300: 200 A4 images / 107 A3 images duplex
  • VarioPrint i300: 168 A4 images / 94 A3 images simplex

• Duty cycle: 1,000,000 – 10,000,000 A4 impressions/month
• Print Resolution: 600x600 dpi with multilevel (1200 dpi perceived)

• Paper Weight: 60–300 gsm
• Substrates: Uncoated, inkjet treated, inkjet coated, offset uncoated, offset coated, tabs, NCR
• Standard Configuration
• 1 Paper Input Module (PIM), Standard PIM or PIM Flex XL
  1 High Capacity Stacker
• Paper Sizes
  • 203 x 203mm - 488 x 320mm
  • 178 x 254mm (with optional guide)
  • 203 x 203 mm - 350 x 500 mm (350 x 508 mm¹) with PIM Flex XL
• Paper Capacity
  • 4,600 sheets A4 (80 gsm) with one PIM
  • 9,200 sheets A4 (80 gsm) with two PIMs
  • 13,800 sheets A4 (80 gsm) with three PIMs
  • 23,400 sheets A4 (80 gsm) with three PIMs and Duo Paper Trays

• Paper Trays
  • 2 x 600 sheets, 2 x 1,700 sheets (80 gsm) standard configuration
  • 2 x 600 sheets, 2 x 3,300 sheets A4 (80 gsm) with Duo Paper Trays
• Standard paper capacity
  • 4,600 sheets standard configuration
  • 7,800 sheets A4 with Duo Paper Trays
• Paper Size
  • 203 x 203 mm - 488 x 320 mm
  • 178 x 254 mm (with optional guide)
• Dimensions (W x D x H): 922 x 1150 x 716 mm
• Weight: 240 kg

• Paper Trays: 2 x 600 sheets, 2 x 1,650 sheets (80 gsm)
• Standard paper capacity: 4,500 sheets
• Paper Size
  • Trays 1 and 2: 203 x 203 mm - 488 x 320 mm
  • Trays 3 and 4: 203 x 208 mm - 350 x 500 mm
• Dimensions (W x D x H): 922 x 1150 x 716 mm
• Weight: 240 kg

• Stacks: 2 x 3,000 sheets (80gsm) per stacker
• Dimensions (W x D x H)
  • 899 x 745 x 1040 mm
  • 899 x 1250 x 1040 mm with stack tray ejected
• Weight: Empty 120 kg, full 300 kg

• Inline camera inspection
• Dimensions (W x D x H): 305 x 745 x 1040 mm
• Weight: 45 kg

• Network Connectivity
  • Internal: 1 x 10 Gbit Ethernet;
  • External: 2 x 1 Gbit (10/100/1000 Base-T)
  • TCP/IP (LPR /LPD, 9100 Socket), Static IP / Auto-IP (DHCP), IPv4, IPv6 (only in Document Printing mode)
• Page description languages
  • PDF 1.7 (Extension Level 3), PDF-X (APPE 4.x RIP support), PDF/VT (Level 1), Postscript, PPML 2.2, IPDS IS/3, SRA PCL6
• Job submission
  • lpr, Hotfolders via WebDAV, Socket (streaming), JDF/JMF, IPP 2.0, Remote PDF Driver
• Protocols
  • SNMP v1, SNMP v3, Host Resources MIB, MIB II, Printer MIB, Job Monitoring MIB, Job Management MIB (partially), IEEE 802.1x
• Spot Color Libraries
  • PANTONE+ Solid (Coated & Uncoated), PANTONE GOE (Coated & Uncoated), HKS (K,N), HKS (K,N) 3000+, PANTONE+ Solid 336 New (Coated & Uncoated)

• Connection Fuse
  • 230/400 VAC, 100A; 100-240 VAC, 13-20A; 100-240 VAC, 13-20A; 200-240 VAC, 13-20A; 100-240 VAC, 13-20A
• Power Consumption – Printing: 14.9 kW
• Power Consumption – Idle: 7.1 kW
• Power Consumption – Sleep: 0.9 kW
• Compressed Air: 5-12 bar, dry and oil free
• Water: Reverse osmosis water system

• Temperature Optimal range 20–26°C
• Humidity Optimal range 30–50%
• Operating noise Printing 72 dB, Standby 61 dB

• Length × Width x Height: 8,800 × 2,750 x 2,400 mm
• Weight: Approximately 8500 kg
