#106433 2006 Mailcrafter 9800 Edge II Swing Arm Insert 98 6 6

ALI Reference #: 106433

2006 Mailcrafter 9800 Edge II Swing Arm Insert 98 6PM
ALI # 106433

The Mailcrafters 9800 6‑Pocket Swing Arm Inserter is a high‑volume production mail inserter designed for direct mail, print finishing, and transactional mailing.
Key Specifications
  • Model: 9800 / 98‑6PM (6‑station swing arm)
  • Insert Stations: 6 (configurable up to 6 or more)
  • Insert Size: 6″ × 9″, up to ¼″ thickness
  • Envelope Size: 6½″ × 9½″ max; 3½″ × 5½″ min
  • Envelope Flap Depth: Up to 2¾″ max (depending on flap construction)
  • Feed System: Swing arm with 6‑pocket collating; vacuum control for document selection
  • Drive System: Conjugated cam drive; rugged industrial construction
  • Operator Interface: Dual control stations (start, jog, reset); safety light bar and emergency stop; some versions with color or touch‑screen panels
  • Power Requirements:
    • 208–240V single phase, 30A
    • 220V three phase, 20A (varies by configuration)
  • Motor: 1.5 HP
  • Current Draw: ~30A (single phase)
  • Frequency: 60 Hz
  • Weight (6‑station conveyor): ~152 lbs (cabinet model adds ~900 lbs)
  • B.T.U. Rating: ~2405 BTU/hr (single phase)

Although we strive for accuracy, some equipment details and specifications are difficult to confirm. Descriptions and specifications of the equipment are not warranties and are intended only as a courtesy. Buyer inspection is encouraged and we recommend to cross-check with the manufacturer for any difference between the machine being sold and what is stated in the listing. There are no warranties or guarantees implied unless otherwise stated. All items are sold "As Is, Where Is, and With All Faults." No guarantee is made as to fitness for a particular purpose, implied or otherwise.
