#106435 2003 Baum Autofold 714 MP Paper Folder

ALI Reference #: 106435

2003 Baum Autofold 714 MP Paper Folder
ALI# 106435

The 2003 Baumfolder 714 Friction Feed Paper Folder is a versatile tabletop folding machine designed for bindery and finishing applications.
Paper Size & Fold Types
  • Sheet size range: 3″ x 5″ to 14″ x 20″ (7.6 x 12.7 cm to 35.5 x 50.8 cm)
  • Folds available: Single fold, Letter fold, Fan fold, French fold, Double-parallel fold, Double letter fold, and Engineering fold
  • Minimum size fold: 2″ (5 cm)
  • Maximum size fold: 13.5″ (34.3 cm) per fold plate
Performance & Feeding
  • Feed table pile height: 2″ (5 cm)
  • Fold roll diameter: 1½″ (3.8 cm)
  • Fold roll width: 14¼″ (35.8 cm)
  • Fold plate depth: 13.5″ (34.3 cm) for both #1 and #2 plates
  • Fold roll material: Urethane
  • Slitter shaft diameter: 7/8″ (2.2 cm)
  • Fold roll speed: Infinitely variable from 0″/min to 7200″/min
Paper Weight Capacity
  • Minimum: 16# bond (60 g/m²)
  • Maximum: 75# cover (203 g/m²)
  • Air feed model max: 65 lb (29.5 kg) cover
Electrical & Mechanical
  • Power: 110 VAC, 60 Hz, 20 amp (NEMA 5-20R)
  • Pump power (air feed model): 1500 W, 13.6 A at 115 V
  • Pump power (air feed model): 14 A, single phase
  • Pump power (air feed model): 250 W folder unit
