Orbital X Anderson & Vreeland CL50 Whirl A Way Polymer Removal System

Orbital X Anderson & Vreeland CL50 Whirl A Way Polymer Removal System
ALI# 106395
Orbital X is a multi‑function, stack‑style plate processor designed for water‑wash plates. It combines washout, exposure, and drying in one unit, with optional detack or post‑expose sections.The Whirl-A-Way CL50 removes polymer residue and extends the lifeof washout solutions. This low-maitenance system uses centrifugal force to separate suspended polymer solids from water flexo washout solutions. The solids are collected in a disposable plastic bag while the clean washout solution is recirculated back into the system for reuse and improved efficiency. The Whirl-A-Way CL-50 is a simple to use system with components easily accessed from the front.
Orbital X
The Anderson & Vreeland Orbital X is a multi‑function, stack‑style plate processor designed for water‑wash plates. It combines washout, exposure, and drying in one unit, with optional detack or post‑expose sections.
Key Features
Temperature‑controlled washout tank (8.5 gallons) with stainless steel wetted parts to prevent corrosion
Magnetic and PVC plate mount with easily adjustable brush mount
Digital timers for accurate washout and exposure control
Vacuum pump for plate handling
Electronic solid‑state ballasts for exposure lamps
Thermostat‑controlled three‑drawer dryer with forced hot air (2250W heaters)
Optional detack or post‑expose light drawer with solid‑state ballasts and safety shut‑off
Optional high or medium output exposure (16 lamps)
Compact, stackable design ideal for crowded workspaces

CL50
Dimensions 24" wide x 27" deep x 48" high
Electrical 20 volts / 1-phase / 60 hertz / 12 amps
Weight 360 lbs
